8-Port Gigabit Smart PoE Switch with 2 SFP Slots TL-SG2210P
Login To See Price
8-Port Gigabit Smart PoE Switch with 2 SFP Slots TL-SG2210P
Shop for 8-Port Gigabit Smart PoE Switch with 2 SFP Slots TL-SG2210P in Nairobi, Kenya at Routine Solutions TP-LINK dealers.
The total PoE power budget of 53W and has enhanced PoE power management features. The 8-Port Gigabit Smart PoE Switch provides high performance, enterprise-level QoS, Can be utilized for creating layer two secure networking.
Key Features:
- 8 PoE ports
- L2/L3/L4 QoS and IGMP snooping to enable you optimize voice and video applications
- Tp-Link TL-SG2210P WEB/CLI managed modes, SNMP, RMON bring abundant management features
- Gigabit Ethernet Speeds for superfast connection
- Security Features including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
Compare
Description
8-Port Gigabit Smart PoE Switch with 2 SFP Slots TL-SG2210P
Shop for 8-Port Gigabit Smart PoE Switch with 2 SFP Slots TL-SG2210P in Nairobi, Kenya at Routine Solutions TP-LINK dealers.
Key Features:
- 8 PoE ports
- L2/L3/L4 QoS and IGMP snooping to enable you optimize voice and video applications
- Tp-Link TL-SG2210P WEB/CLI managed modes, SNMP, RMON bring abundant management features
- Gigabit Ethernet Speeds for superfast connection
- Security Features including 802.1Q VLAN, ACL, Port Security and Storm control help protect LAN area investment
HARDWARE FEATURES | |
STANDARDS AND PROTOCOLS | IEEE 802.3i, IEEE 802.3u, IEEE 802.3z, IEEE 802.3ab, IEEE 802.3ad, IEE 802.3af, IEEE 802.3x, IEEE 802.1d, IEEE 802.1s, IEEE 802.1w, IEEE 802.1q, IEEE 802.1p, IEEE 802.1x |
INTERFACE | 8 10/100/1000Mbps RJ45 Ports 2 1000Mbps SFP Slots (Auto-Negotiation/Auto MDI/MDIX) |
NETWORK MEDIA | 10BASE-T: UTP category 3, 4, 5 cable (maximum 100m) 100BASE-TX/1000Base-T: UTP category 5, 5e or above cable (maximum 100m) 1000BASE-X: MMF, SMF |
FAN QUANTITY | Fan less |
POWER SUPPLY | 100~240VAC, 50/60Hz External Power Adapter(Output: 48VDC/1.25A) |
POWER CONSUMPTION | Maximum (PoE on): 63.4W (220V/50Hz) Maximum (PoE off): 10.4W (220V/50Hz) |
POE PORTS (RJ45) | Standard: 802.3af compliant PoE Ports: 8 Ports Power Supply: 53W |
DIMENSIONS ( W X D X H ) | 8.2 x 4.9 x 1.0 in (209 x 126 x 26mm) |
PERFORMANCE | |
BANDWIDTH/BACKPLANE | 20Gbps |
PACKET FORWARDING RATE | 14.9Mpps |
MAC ADDRESS TABLE | 8k |
PACKET BUFFER MEMORY | 512KB |
JUMBO FRAME | 9216 Bytes |
SOFTWARE FEATURES | |
QUALITY OF SERVICE | Support 802.1p CoS/DSCP priority Support 4 priority queues Queue scheduling: SP, WRR, SP+WRR Port/Flow- based Rate Limiting Voice VLAN |
VLAN | Supports up to 512 VLANs simultaneously (out of 4K VLAN IDs) |
ACCESS CONTROL LIST | L2~L4 package filtering based on source and destination MAC address, IP address, TCP/UDP ports, 802.1p, DSCP, protocol and VLAN ID Time Range Based |
SECURITY | SSH v1/v2 SSL v2/v3/TLSv1 Port Security Broadcast/Multicast/Unknown unicast Storm Control 802.1x and Radius Authentication IP-Mac-Port-VID Binding、ARP Inspection、DHCP Snooping、DoS Defend |
L2 SWITCHING FEATURES | IGMP Snooping V1/V2/V3 802.3ad LACP (Up to 6 aggregation groups, containing 4 ports per group) Spanning Tree STP/RSTP/MSTP BPDU Filtering/Guard TC/Root Protect Loop back detection 802.3x Flow Control LLDP(LLDP-MED) |
MANAGEMENT | Web-based GUI and CLI management SNMP v1/v2c/v3, compatible with public MIBs and TP-LINK private MIBs RMON (1, 2, 3, 9 groups) CPU Monitoring Port Mirroring Time Setting: SNTP Firmware Upgrade: TFTP & Web System Diagnose: VCT SYSLOG & Public MIBS |
OTHERS | |
CERTIFICATION | CE, FCC, RoHS |
PACKAGE CONTENTS | TL-SG2210P Power Adapter Installation Guide Resource CD Rubber Feet |
SYSTEM REQUIREMENTS | Microsoft® Windows® 98SE, NT, 2000, XP, Vista™ or Windows 7/8, MAC® OS, NetWare®, UNIX® or Linux. |
ENVIRONMENT | Operating Temperature: 0℃~40℃ (32℉~104℉); Storage Temperature: -40℃~70℃ (-40℉~158℉) Operating Humidity: 10%~90% non-condensing Storage Humidity: 5%~90% non-condensing |
