MikroTik RB2011UiAS-RM

Product Specifications:

DETAILS
Product codeRB2011UiAS-RM
ArchitectureMIPSBE
CPUAR9344
CPU core count1
CPU nominal frequency600 MHz
Dimensions214mm x 86mm for PCB
License level5
Operating SystemRouterOS
Size of RAM128 MB
Storage size128 MB
Storage typeNAND
Tested ambient temperature-35C to +65C
Suggested price$119.00

Powering

DETAILS
Max Power consumption6W
PoE inPassive PoE
PoE outPassive PoE
PoE in input Voltage8-30 V
Number of DC inputs2 (DC jack, PoE-IN)
DC jack input Voltage8-30 V

Ethernet

DETAILS
10/100 Ethernet ports5
10/100/1000 Ethernet ports5

Fiber

DETAILS
SFP DDMIYes
SFP ports1

Peripherals

DETAILS
Serial portRJ45
Number of USB ports1
USB Power ResetYes
USB slot typeUSB type A
Max USB current (A)2

Other

DETAILS
PCB temperature monitorYes
Voltage MonitorYes



Compare

Description

MikroTik RB2011UiAS-RM

Shop for MikroTik RB2011UiAS-RM in Nairobi from Routine mikrotik dealers

DESCRIPTION

RouterBoard 2011UiAS-RM

The RouterBoard 2011UiAS-RM can be considered a landmark especially if it’s compared with the other router boards in the series like RouterBoard 2011UAS. It is not only affordable but it’s loaded with various handy and nifty features.

Easy and Fast Connectivity

The RouterBoard 2011 UAS-RM now has 5 LAN ports along with 5 fast Ethernet ports. What’s more, you can make use of an RJ45 connector for the serial port and a microUSB port. In other words, you can design different types of network schemes with this router board. You can go for something simple to something more intricate or complex, serving various network users and sharing bigger content without compromising the speed and performance of the Internet.

Quick Configuration

Along with the power supply, the RouterBoard 2011UiAS-RM’s package includes a rack mount enclosure. There’s also an SFP cage, so the only thing to think about is the module. There’s n LCD panel that’s touch screen so you won’t have a hard time configuring the device. It also has an auto-MDI/X capability, which means it adjusts itself depending on what cable wires you attach. There’s no need to guess or go through trial and error when it comes to cables.

Great Support

The router board is fitted with the Level 5 RouterOS, which gives you a month of excellent initial configuration support from MikroTik. You can also set up the router board into a wireless access point and bridge and enjoy 500 PPPoE, L2TP, and PPTP tunnels, as well as unlimited OVPN and VLAN interface support. Other benefits include 500 hotspot active users, support for RADIUS client, unlimited queues, unlimited KVM guests, 50 user manager active sessions, and support for RIP, BGP, and OSPF protocols. It is equipped with 128MB RAM, NAND Flash, and Atheros AR9344 running on 600MHz.

PoE output

There is PoE output function for port #10 – it can power other PoE capable devices with the same voltage as applied to the unit. Maximum load on the port is 500mA.
